Data Modeling 101: The Importance of Data Modeling in Data Engineering/Analytics

Introduction to Data Modeling

Have you ever wondered how large organizations manage and analyze large volumes of data? That's where data modeling comes into play. It provides a conceptual representation of the data, making it easier to store, retrieve, and analyze. Data modeling is an essential component of data engineering and analytics that enables businesses to make informed decisions based on reliable and accurate data.

In this article, we will dive into key concepts for data modeling, including metrics/KPIs, normalization, slowly changing dimensions (SCD), and entity relationship diagrams (ERD).

What Is Data Modeling?

Data modeling is a process that involves creating a conceptual representation of data, which can then be used to build a database schema. This process helps to organize data in a way that makes it easy to use, understand, and analyze.

​How can a data infrastructure platform help?​

Think of it like creating a map that shows how all the different pieces of data are related to each other. By visualizing this information, you can better understand the patterns, constraints, and relationships within the data. This, in turn, helps you design effective data systems, like data warehouses or lakes, that can support your organization's goals.

Simply put, data modeling is like building a well-planned highway system that efficiently directs traffic flow while ensuring good road conditions and minimal traffic jams. Just as traffic engineers analyze traffic patterns and usage to design an optimal system, data modelers use their knowledge of data structures and relationships to create an organized and streamlined system for data flow.

One example of a startup that uses data modeling effectively is Airbnb. They have a complex system that handles millions of bookings annually, and data modeling is critical to keep everything running smoothly. By understanding the relationships between different data points, Airbnb can quickly and accurately match guests with the perfect rental properties, ensuring a positive experience for both hosts and guests.

Why Is It Important in Data Engineering/Analytics?

Data modeling plays a critical role in data engineering and analytics, especially in today's fast-paced and ever-changing data landscape. It allows businesses to organize large volumes of data into a structure that is easy to understand and use, enabling them to extract valuable insights and make data-driven decisions that can improve their bottom line. Ensuring that data is accurate, consistent, and reliable is also essential for informed decision-making based on reliable data.

Data modeling is often overlooked in data projects due to factors such as time constraints, a fast-paced development environment, or a lack of expertise. Rather than investing time in creating a well-structured data architecture, businesses tend to rush to develop their projects, resulting in a subpar minimum viable product.

However, having a solid data model and strategy is crucial for any data project's success. It involves incorporating business logic into the data flow through SQL/Python code, drag-and-drop ETL tools, or modern Business Rule Engines. This allows data to flow efficiently with good quality and minimal redundancy, resulting in better decision-making and a competitive advantage in the market.

For example, consider the startup company Lawn Guru which provides on-demand lawn care services. Lawn Guru uses data modeling to analyze customer behavior and predict when they will need services. By doing so, they can efficiently allocate resources, leading to better customer experiences and a more profitable business.

Different Levels of Data Modeling

Data modeling involves three different levels: conceptual, logical, and physical. Each level serves a specific purpose and provides a unique perspective on the data being modeled.

Conceptual Data Modeling

Conceptual data modeling is the highest level of abstraction and is used to define the business concepts and rules that apply to the data. It focuses on the relationships between different data entities, without getting into the specifics of how the data is stored or accessed.

In the above diagram, we are looking at an example of Conceptual Data Modeling in a retail Setup.

Logical Data Modeling

Logical data modeling takes the conceptual model and adds more detail, defining the data elements, their relationships, and the business rules governing the data. This model provides a blueprint for how the data will be stored, organized, and accessed.

In the above diagram, we are looking at an example of Logical Data Modeling in a similar retail setup in the same way that we observed previously in the example for Conceptual Data Modeling.

Physical Data Modeling

Physical data modeling is the lowest level of abstraction and focuses on the physical implementation of the data model. It defines how the data will be stored in databases and how it will be accessed by applications.

In the above diagram, we are looking at an example of Physical Data Modeling in the same retail setup in the same way that we observed previously in the examples for Conceptual Data Modeling, and Logical Data Modeling.

Data modeling can be applied at different levels, including the generation or source database, data integration and ETL processes, data warehouse, data lake, BI tools and reporting, and machine learning and AI. By integrating business logic into data modeling, organizations can ensure that their data architecture is aligned with their objectives and supports effective decision-making.

Below is a table summarizing the differences between Conceptual, Logical, and Physical Modeling:

The History of Data Modeling: A Quick Recap

Data modeling has a rich history that has evolved with technological advances and changing business requirements. The evolution of data modeling can be divided into a few key phases.

In the early days of data management (the 1960s-1970s), hierarchical and network data models emerged as the primary techniques. This laid the foundation for more advanced data models. However, Business Intelligence (BI) and data warehousing were still in their infancy.

The emergence of relational databases (the 1980s) revolutionized data modeling and management. The relational model introduced by Edgar F. Codd enabled the development of the Entity Relationship Diagram (ERD) model, which became the primary method for designing and implementing databases for transactional systems.

The birth of data warehousing and BI (the 1990s) saw BI and data warehousing gain prominence. Dimensional modeling, introduced by Ralph Kimball,  became the standard for data warehouse design. Bill Inmon proposed another method called the top-down approach, that focused on the creation of a normalized and enterprise-wide data model. Inmon’s and Kimball’s methods addressed the challenges of reporting and analyzing data for decision-making.

As more and more data sources became available in the 2000s, organizations began gathering and analyzing data from various sources, including the Internet and social media. This led to an explosion in the volume, variety, and velocity of data, which in turn led to the development of new technologies and platforms like Hadoop, NoSQL databases, and data lakes. To keep up with this constantly changing data landscape, data modeling had to evolve to incorporate these new data types and storage systems.

Create a Unique Brand Identity

In today's world of data engineering (the 2010s-present), the data ecosystem has become increasingly complex and diverse. With the advent of cloud computing, advanced analytics, and machine learning, data modeling now needs to be able to handle various data sources, formats, and storage technologies like cloud-based data warehouses, data lakes, and real-time streaming data. It's an exciting time for data engineering and modeling, with endless possibilities for innovation and growth.

The Era of Big Data and NoSQL Databases

The expansion of data sources and big data in the 2000s led to the emergence of big data technologies and platforms like Hadoop, NoSQL databases, and data lakes. Data modeling in this context had to adapt to the changing landscape, incorporating new data types and storage systems.

NoSQL databases are a type of database that doesn't use the traditional SQL query language, and instead use more flexible data models such as document, key-value, or graph databases. NoSQL databases provide scalability and high availability, which make them ideal for big data scenarios.

However, NoSQL databases have their own unique challenges when it comes to data modeling. Since they don't have a rigid schema, data modeling is more flexible but requires a different approach. It is important to understand the data access patterns and query requirements to design an effective data model in a NoSQL database.

Data Modeling for the Cloud Era

With the rise of cloud computing, advanced analytics, and machine learning in the 2010s, data modeling has once again become a critical component of data management. Data modeling in the modern data engineering landscape needs to accommodate various data sources, formats, and storage technologies, such as cloud-based data warehouses, data lakes, and real-time streaming data.

In this landscape, data modeling has become more complex, with the need to incorporate both structured and unstructured data, as well as different types of data storage systems. Additionally, data modeling needs to be able to handle the integration of data from various sources and ensure data quality and accuracy.

To meet these challenges, data engineers are developing new data modeling techniques and tools that can handle the modern data landscape. This includes techniques like schema-on-read, which allows for more flexibility in data modeling, and tools like Apache Spark and TensorFlow, which provide advanced analytics and machine learning capabilities.

Why Has Data Modeling Lost Its Popularity?

Data modeling is an essential aspect of data management that has been in use for decades. However, over the years, its popularity has declined. Some businesses have misunderstood data modeling as rigid and inflexible, leading them to shy away from using it in their data management processes. This misunderstanding has led to the rise of alternative approaches to data modeling.

Misunderstanding of Data Modeling

Data modeling involves creating a conceptual representation of data structures and relationships to support specific business needs. It is a complex process that requires a deep understanding of the data being modeled. However, some businesses have misunderstood data modeling as rigid and inflexible. They believe that it takes too long to develop and implement a data model and that it is not worth the effort. However, this is not the case, and data modeling is a crucial aspect of data management.

Alternative Approaches to Data Modeling

To address the limitations of traditional data modeling techniques, businesses are now exploring alternative approaches to data modeling. One of these approaches is schema-on-read. This technique allows data to be stored in a flexible, unstructured format, and the schema is applied only when the data is read. This approach allows for more flexibility in data modeling and is becoming increasingly popular among businesses that need to store and analyze large volumes of data.

Why Did the Importance of Data Modeling Rise?

In recent years, the importance of data modeling has risen again due to the complexity of data. With the rise of big data, businesses are dealing with massive amounts of data that come in different formats and from various sources. As a result, data modeling has become a critical component of data management.

The Complexity of Data

The complexity of data is one of the main reasons for the renewed importance of data modeling. The sheer volume, variety, and velocity of data make it difficult to manage and analyze without proper data modeling.

The Need for Data Consistency

Data consistency is another important factor that has led to the rise in the importance of data modeling. Inaccurate or inconsistent data can lead to poor decision-making and ultimately, negative business outcomes. Data modeling helps ensure data consistency by providing a standardized framework for storing and accessing data.

The Emergence of New Technologies

New technologies like cloud computing, advanced analytics, and machine learning have also contributed to the renewed importance of data modeling. These technologies require a more flexible and dynamic approach to data modeling that can accommodate various data sources, formats, and storage technologies. For example, cloud-based data warehouses and data lakes require different data modeling techniques than traditional relational databases.

Startups like Airbnb, Lyft, and Uber have embraced data modeling to support their business needs. These companies collect large amounts of data from various sources, and data modeling is critical to ensure data consistency and accuracy. Airbnb probably uses data modeling to ensure the consistency of data, enabling the company to improve its decision-making capabilities. Similarly, Lyft probably uses data modeling to manage the large amounts of data generated by its ride-sharing platform.

Key Concepts for Data Modeling

Data modeling is the process of creating a conceptual representation of data structures and relationships to support a specific business need. Some of the key concepts involved in data modeling include metrics/KPIs, normalization, slowly changing dimensions, and entity relationship diagrams.

Metrics/KPIs

Metrics and Key Performance Indicators (KPIs) are important aspects of data modeling as they help to measure the success of business processes. KPIs provide a quantifiable way to measure progress toward specific goals or objectives. For example, a retail startup may use metrics such as sales per square foot or inventory turnover rate to assess the performance of its stores.

Normalization: Normalized vs. Denormalized

Normalization is the process of organizing data in a database to reduce redundancy and improve data integrity. Normalization involves breaking up large tables into smaller ones and establishing relationships between them. This approach is useful for ensuring consistency and minimizing errors in data. A real-world example to visualize this would be a giant-joint family divided into nucleated families minimizing the usage of resources and conflicts internally as a whole.

On the other hand, denormalization is the process of combining tables to improve performance in certain situations. This approach is useful for complex queries or data warehousing, where query speed is more important than data consistency.

History or Slowly Changing Dimension (SCD)

Slowly Changing Dimensions (SCDs) are used in data warehousing to manage data that changes over time. This can include things like customer addresses, product prices, or employee information. The history of SCDs can be traced back to the early days of data warehousing in the 1980s.

There are different types of SCDs, including Type 1, Type 2, and Type 3. Each type handles changes in data differently, depending on the specific business requirements.

Entity Relationship Diagram (ERD)

An Entity Relationship Diagram (ERD) is a visual representation of the relationships between different entities in a database. ERDs are used to model complex data structures and can be used to help design new databases or modify existing ones.

ERDs are made up of entities, which represent real-world objects or concepts, and relationships, which represent the connections between entities. For example, a retail startup may have entities for customers, orders, and products, with relationships between them representing things like which customers have placed which orders, and which products have been ordered by which customers.

Data Modeling to the Rescue

As discussed earlier, data modeling is a critical process in the data engineering landscape that helps organizations create a conceptual representation of data structures and relationships to support specific business needs. It helps in developing a blueprint of how data should be stored, accessed, and updated to ensure data quality and consistency, simplify data retrieval and analysis, and enable scalability and flexibility.

Improving Data Quality and Consistency

One of the primary benefits of data modeling is improving data quality and consistency. By creating a conceptual representation of data structures and relationships, data engineers can identify data inconsistencies, redundancies, and errors, and take corrective measures to improve data quality. This helps in ensuring that the data used for business decision-making is accurate and reliable.

According to a study by IBM, "poor data quality costs US businesses an estimated $3.1 trillion annually." This emphasizes the importance of data modeling in improving data quality and consistency, and the need for organizations to invest in data modeling tools and techniques.

Simplifying Data Retrieval and Analysis

Data modeling also simplifies data retrieval and analysis by organizing data in a logical and efficient manner. It helps in identifying the data required for specific business needs, and how the data should be retrieved and analyzed. This simplifies the data retrieval process and enables organizations to make informed decisions based on accurate and relevant data.

For example, startup company Molekule, which creates air purifiers, probably uses data modeling to organize and analyze data from various sources, such as sensors and user feedback, to develop new products and features. By using data modeling, they can quickly retrieve and analyze the relevant data required for product development, and make informed decisions based on accurate and reliable data.

Enabling Scalability and Flexibility

Data modeling also enables scalability and flexibility by providing a blueprint for how data should be stored and accessed. By designing a flexible data model, organizations can easily adapt to changes in data sources and storage technologies, and scale their data management systems to meet growing business needs.

For example, Airbnb uses data modeling to enable scalability and flexibility in its data management systems. Airbnb’s engineering team built a key-value store called Mussel that was built using a combination of Apache Helix, HBase, and Kafka. Mussel served 4 key requirements: Scale, Bulk and Real-time Loading, Low Latency, and Multi-tenant.

By using this flexible data model, Airbnb can easily scale its data management systems as its business grows, without having to re-design its entire data management system.

DBT and Data Modeling

If you're a data engineer or analyst, managing data models can be a challenging task, especially when dealing with large volumes of data. But don't worry, DBT (Data Build Tool) has got you covered! DBT is an open-source tool that allows teams to define data models using SQL and version control them on a git repository. This helps to maintain consistency and avoid errors in data modeling.

What's more? DBT allows you to test your data models before deploying them to production, so you can catch any errors early on and ensure the data is accurate and reliable. And if you need to create documentation for your data models, DBT can help you with that too. It's a win-win!

But that's not all. DBT also has a powerful feature called materialized views. Materialized views are pre-calculated tables that store the results of a query. This can significantly speed up queries and reduce the time it takes to retrieve data. This feature can be particularly useful for frequently queried data and can eliminate the need for repeated calculations.

DBT can also help you manage incremental data loading. This means that you can configure your data models to load only new or updated data, reducing the time and resources required to maintain data pipelines. So, you can rest assured that your data is always up-to-date and optimized for efficiency.

Some companies that use DBT in their data stack include the following - Cyndx, Hitachi Solutions, Blend360, Mediavine, Travelers, and Ken Garff.

Materialized Views

Materialized views can be a game-changer for startups that need to work with large volumes of data. They are pre-calculated tables that store the results of a query, which means that you don't have to wait for the query to run every time you need to analyze the data. Instead, the data is already there, pre-aggregated, and ready to go.

For example, a startup that needs to track customer behavior over time can create a materialized view that aggregates data on a daily basis. This can be used to create reports or dashboards, saving a lot of time and resources compared to running the same queries repeatedly. It's important to note that materialized views do require storage space, but the trade-off is often worth it in terms of the time saved and increased efficiency of data retrieval and analysis.

Materialized views are just one of many tools that data engineers and analysts have at their disposal. However, they are particularly useful for frequently queried data and can speed up queries, saving time and resources.

Conclusion

Data modeling is a crucial aspect of data engineering and analytics that enables the efficient storage, retrieval, and analysis of large volumes of data. In this article, we have dived into an in-depth introduction to data modeling, covering its different levels and importance. We also explored why data modeling lost its popularity and how its importance has risen again due to the complexity of data. We also discussed the key concepts for data modeling, including metrics/KPIs, normalization, slowly changing dimensions (SCD), and entity relationship diagrams (ERD).

Do keep in mind that data modeling is not just limited to databases, but it also extends to modern data engineering tools such as DBT and materialized views. These tools have further enhanced the importance of data modeling by improving data quality and consistency, simplifying data retrieval and analysis, and enabling scalability and flexibility.

In today's fast-paced world of data engineering and analytics, the importance of data modeling cannot be overstated. It's the key to unlocking the power of your data and leveraging it to drive growth and success. And when it comes to data modeling, we recommend giving Datazip a try.
